Add enhanced bass to your movies and music with the ELAC Debut 2.0 SUB3030 12" 1000W Subwoofer. This subwoofer features a 12" high-excursion doped paper woofer with a 12" downward-facing passive radiator and delivers up to 500W of RMS power, or up to 1000W of peak power. With a frequency response of 25 to 150 Hz, the SUB3030 is equipped to handle a variety of listening material.
Features:
- 12" High-Excursion Doped Paper Woofer
- 12" Downward-Facing Passive Radiator
- Up to 500W RMS / 1000W Peak Power
- BASH-Tracking Amplification
- 25 to 150 Hz Frequency Response
- Bluetooth 4.0 LE Setup & Control
- Front-Firing Configuration
- Bluetooth LE Mobile Device Required
Video Review:
BASH (Bridged Amplifier Switching Hybrid) Amplifier
The BASH amplifier uses a Class D amplifier with power supply modulation to track the input signal, supplying only the necessary voltage to the Class AB amplifier as needed.
Bluetooth Control
Doing away with traditional analog controls, the SUB3030 incorporates an all-digital control system. Download the ELAC SubEQ app for your compatible Android or iOS device (with Bluetooth 4.0 LE) and you'll have complete control of multiple subwoofers at the same time.
Auto EQ
With the SubEQ app and your smartphone's microphone, the subwoofer can optimize room EQ automatically using eight parametric curves; full manual EQ is available as well.
Long-Throw Driver
The 12" long-throw driver is designed to accurately reproduce the quality and quantity and bass for both movie soundtracks and music. A 12" passive radiator helps enhance transient response and increase system efficiency.
Braced MDF Cabinet
The horizontal center brace is designed to strengthen and stiffen the cabinet, helping to minimize unwanted vibrations that can discolor music or movie content. It also helps to reproduce low frequencies precisely, without overhang or distortion.
Auto Power On/Off
The subwoofer will detect when an audio signal is being sent to the amplifier and will power on. Also, to conserve energy, the subwoofer will power off after a long period of inactivity.
Technical Specifications:
Subwoofer |
|
Subwoofer Type |
Active |
Amplifier Power Rating |
500 W RMS 1000 W Peak |
Drivers |
1 x 12" / 30.5 cm Paper |
Frequency Response |
25 to 150 Hz |
Amplifier Class |
BASH |
Connectivity |
1 x Stereo RCA Input (LFE) 1 x USB Type-A (Service) |
Crossover Frequency |
50 to 150 Hz |
Power |
|
AC Input Power |
100 to 240 VAC, 50 / 60 Hz at 2 A |
Power Consumption |
1 W (Standby) |
Physical |
|
Cabinet Material |
MDF |
Dimensions |
18.2 x 17 x 17" / 46.2 x 43.2 x 43.2 cm |
Weight |
50.2 lb / 22.8 kg |
Packaging Info |
|
Package Weight |
60 lb |
Box Dimensions (LxWxH) |
23 x 22 x 22" |
